MHY2-16D

180°Angular Type Air Gripper Cam Type MHY2 Series

Stainless steel gripper with high strength and corrosion resistance. Fully hard anodized. Minor scratches will not leave any marks.
High-quality spring clips imported seals. Imported self-lubricating sealing components prevent cylinder leakage; durable, wear-resistant, with small errors and high efficiency.
Simplifying the picking-up and placing actions can prevent foreign objects from entering and is suitable for use in special environments.180°opening and closing。
To adapt to the scenarios with limited installation space, the guide rails are equipped with two optional air intake designs for enhanced performance.
Cylinder with magnetic sensitivity. Suitable for D-A93 and other magnetic switches. Detects the movement state by sensing the circular magnetic grooves. Can be directly installed.
